Protocol for Inoculation of PGPR Staphylococcus sciuri to Seeds and Seedlings of Rice and Tomato Plants for Increased Root and Shoot Growth

Materials and reagents

Biological material

1. Bacterial strain Staphylococcus sciuri ET101, halotolerant PGPR isolated from the rhizosphere of Salicornia species

2. Oryza sativa (Aiswarya cultivar), purchased from Regional Agricultural Research Station, Pattambi, Kerala, India

3. Lycopersicon esculentum (PKM seeds), purchased from Sri Venkateswara Agro Store, Tiruchirappalli, Tamil Nadu, India

Reagents

1. LB agar (SRL, catalog number: LM018)

2. LB broth (Himedia, catalog number: M1245)

3. Absolute ethanol (Analytic CS Reagent, catalog number: 1170)

4. Sodium hypochlorite (Nice, catalog number: S2195)

5. KCl (Merck, catalog number: 1.93238.0521)

6. NaCl (Merck, catalog number: 1.93606.0521)

7. Na₂HPO₄ (Merck, catalog number: 1.93209.0521)

8. KH₂PO₄ (Merck, catalog number: 1.93205.0521)

9. NaOH (SRL, catalog number: 68151)

10. HCl (Finar, catalog number: 70770L8M50)

Solutions

1. 10× phosphate-buffered saline (PBS) (see Recipes)

Recipes

1. 10× phosphate-buffered saline (PBS)

Reagents	Final concentration
NaCl	1.37 M
KCl	27 mM
Na2HPO4	100 mM
KH2PO4	18 M
Sterile distilled water	Make up to 1 L

Adjust the pH to 7.4 with 1N NaOH or 1N HCl.

Laboratory supplies

1. Culture bottles (Tarsons, catalog number: 20080)

2. Pots (Garden Aids, India, catalog number: AP-3)

3. Micropipettes (Eppendorf Research Plus, catalog number: 35016146026)

4. Petri dishes, 90 mm (Abdos, catalog number: 3165077)

5. 2 mL Eppendorf tubes (Abdos, catalog number: P10203)

6. 50 mL centrifuge tubes (Falcon, catalog number: 546024)

7. Filter paper (Sigma, catalog number: FP/310/AC)

8. Forceps (HiMedia, catalog number: LA821)

9. Cotton (HiMedia, catalog number: LA1018)

10. Parafilm (Tarsons, catalog number: 380020)

11. Red soil (PKM Nursery, Thiruvarur, Tamil Nadu)

12. Soilrite (Keltech Energies Limited, HSN code: 68062000)

13. Perlite (Keltech Energies Limited, HSN code: 27030090)

Equipment

1. Weighing balance (Shimadzu, model: ATX224)

2. Autoclave (Equitron, model: PAD NC01HF28837)

3. Centrifuge (Thermo Fisher, model: SORVALST16R)

4. Orbital shaker (C-Being Scientific Inc. model: BSI-3C)

5. Laminar air flow (Lab field, model: LFAS-110)

6. Plant growth chamber (SRL, model: PGC- 11)

7. UV spectrophotometer (Shimadzu, model: UV-1800)

Software and datasets

1. UV probe 2.0

Procedure

Notes:

1. The whole sterilization process should be done in a laminar air flow chamber.

2. Use autoclaved 50 mL centrifuge tubes (Falcon tubes).

A. Seed sterilization

1. Pre-soak rice and tomato seeds in water for 3 h.

2. Transfer 150 rice seeds (Aiswarya) into a 50 mL centrifuge tube and tomato PKM-1 seeds to a 2 mL Eppendorf tube. Add 8 mL of 70% ethanol to Aiswarya seeds and 2 mL of 70% ethanol to tomato seeds.

3. Incubate the seeds for 2 min at room temperature.

4. Discard ethanol and rinse twice with sterile distilled water.

5. Add 8 mL of 4% sodium hypochlorite to rice seeds and 2 mL to tomato seeds.

6. Incubate for 3 min at room temperature with gentle shaking.

7. Discard sodium hypochlorite and rinse the seeds vigorously with sterile water five times.

8. Air dry the sterilized seeds on sterile filter paper for 15–20 min.

Note: The entire sterilization process should be done in a laminar air flow chamber.

B. Bacterial culture

1. Primary culture

a. Add a single colony from a freshly prepared LB agar plate to 15 mL of LB broth.

b. Incubate it overnight at 30 °C and 180 rpm in an orbital shaker.

2. Secondary culture

a. Add 200 μL of the primary culture to 40 mL of LB broth.

b. Incubate it at 30 °C and 180 rpm in an orbital shaker until OD₆₀₀ reaches 0.8.

3. Processing of bacterial culture

a. Centrifuge the bacterial culture at 3,522× g for 5 min to pellet down the bacterial cells.

b. Discard the media components (supernatant) and dissolve the pellet in 10 mL of 1× PBS.

c. Centrifuge the resuspended pellet at 3,522× g for 5 min.

d. Wash the pellet thrice by resuspending it in 1× PBS followed by centrifugation at 3,522× g for 5 min.

e. Resuspend the pellet either in 1× PBS or in sterile distilled water.

Note: Gently dissolve the pellet, do not shake vigorously.

C. Seed treatment with the bacterial inoculum and different growth conditions

1. Seed treatment with bacteria

a. Transfer sterilized seeds from section A to pellets resuspended in 1× PBS or water from section B using sterile forceps.

b. Transfer sterilized seeds from section A to 1× PBS or water (uninoculated control).

c. Incubate overnight in an orbital shaker at 30 °C and 180 rpm.

Note: After incubation, transfer seeds to sterile culture bottles for germination or directly to pots with sterile soil.

2. Different developmental stages

a. Early developmental stage (tissue culture bottles):

i. Place a thin layer of absorbent cotton in a sterile culture bottle and autoclave it at 121 °C (15 psi) for 20 min.

ii. Open the culture bottle inside the laminar hood and add 3 mL of autoclaved distilled water.

iii. Transfer ten seeds to the respective bottles, close them, and seal them with parafilm.

iv. Keep the bottles in the dark for 3 days for germination.

v. After germination, transfer the culture bottles to a growth chamber with 8/16 h light/dark photoperiod with 140 μmol·m^-2·s^-1 light intensity for 10 days.

b. Late developmental stage (pot study):

i. Wash the pots (200 mL capacity) and label them with the respective treatments.

ii. Take red soil, soilrite, and perlite in a 3:1:1 ratio and autoclave.

iii. Fill three-fourths of the 200 mL pots with sterile soil (150 g) and drench it with water.

Note: Treated seeds can be transferred directly to the pots or germinated in Petri plates for three days in the dark and then transferred to soil.

iv. Place treated seeds in the pots and cover them with a thin layer of sterile soil mix.

v. Place pots in a growth chamber with 8/16 h light/dark photoperiod with 140 μmol·m^-2·s^-1 light intensity at 22 °C.

3. Soil drenching with culture

a. Plants are ready for culturing ten days after germination.

b. After the secondary culture reaches 0.8 OD₆₀₀, centrifuge the bacterial cells at 3,522× g for 5 min and discard the supernatant.

c. Wash the pellet thrice with 1× PBS and resuspend the cells in water.

d. Add 5 mL of pellet-resuspended water to each pot with bacterial treatment on days 11, 13, and 15 after germination.

e. Subsequent bacterial inoculation to plants is done every 15 days.

f. Add 5 mL of water to control plants.

Data analysis

PGPR inoculation on seeds and seedlings of plants was performed as shown in the Graphical overview. Uninoculated and PGPR-inoculated plants were taken out of culture bottles after 10 days of germination, and the root and shoot lengths were measured. Changes in root and shoot growth were monitored during late developmental stages from soil-grown plants.

Validation of protocol

Validation of this protocol is done by analyzing changes in the growth of monocot (Oryza sativa) and dicot (Lycopersicon esculentum) plants. Compared to uninoculated plants, improved root growth and shoot length were observed in inoculated plants in both early (10-day-old seedlings) and late developmental stages (2-month-old plants) (Figure 1) [12].

Figure 1. Analyzing uninoculated (UI) and S. sciuri–inoculated (I) plants for improved growth. Root and shoot growth enhancement is observed in the early developmental stage (10-day-old seedlings) and late developmental stages (2-month-old plants) of tomato and rice plants inoculated with Staphylococcus sciuri ET101.

Acknowledgments

The authors acknowledge the SERB, India funded project (EEQ/2021/000498) to DC, Department of Biotechnology and Department of Microbiology, Central University of Tamil Nadu for common facilities.

Competing interests

The authors declare that they have no known competing financial interests or personal relationships that could have appeared to influence the work reported in this paper.

Ethical considerations

The information and work involved in this paper is submitted with ethical standards.

References

1. Raaijmakers, J. M., Paulitz, T. C., Steinberg, C., Alabouvette, C. and Moënne-Loccoz, Y. (2009). The rhizosphere: a playground and battlefield for soilborne pathogens and beneficial microorganisms. Plant Soil. 321: 341–361. https://doi.org/10.1007/s11104-008-9568-6
2. Olanrewaju, O. S., Glick, B. R. and Babalola, O. O. (2017). Mechanisms of action of plant growth promoting bacteria. World J Microbiol Biotechnol. 33(11): 197. https://doi.org/10.1007/s11274-017-2364-9
3. Somna, G., Challabathula, D. and Bakka, K. (2023). Nanobiofertilizers: Applications, Crop Productivity, and Sustainable Agriculture. In: Kamel A. Abd-Elsalam and Mousa A. Alghuthaymi. (eds.). Nanofertilizers for Sustainable Agroecosystems. Recent Advances and Future Trends: Nanotechnology in the Life Sciences, Springer. pp 233–258. https://doi.org/10.1007/978-3-031-41329-2_9
4. Abhilash, P., Dubey, R. K., Tripathi, V., Gupta, V. K. and Singh, H. B. (2016). Plant Growth-Promoting Microorganisms for Environmental Sustainability. Trends Biotechnol. 34(11): 847–850. https://doi.org/10.1016/j.tibtech.2016.05.005
5. Etesami, H. (2020). Plant–microbe interactions in plants and stress tolerance. Plant Life Under Changing Environ. 2020: 355–396. https://doi.org/10.1016/b978-0-12-818204-8.00018-7
6. Bakka, K., Gopika, P. V., Sreelakshmi, H. and Challabathula, D. (2022). Halotolerant Plant Growth Promoting Rhizobacteria: A Futuristic Direction to Salt Stress Tolerance. In: Roy, S., Mathur, P., Chakraborty, A.P., Saha, S.P. (eds.). Plant Stress: Challenges and Management in the New Decade. Advances in Science, Technology & Innovation. Springer. 277–293. https://doi.org/10.1007/978-3-030-95365-2_17
7. Mahmood, A., Turgay, O. C., Farooq, M. and Hayat, R. (2016). Seed biopriming with plant growth promoting rhizobacteria: a review. FEMS Microbiol Ecol. 92(8): fiw112. https://doi.org/10.1093/femsec/fiw112
8. Bakka, K. and Challabathula, D. (2020). Amelioration of Salt Stress Tolerance in Plants by Plant Growth-Promoting Rhizobacteria: Insights from “Omics” Approaches. In: Varma, A. et al. (eds.). Plant Microbe Symbiosis, Springer Nature. 303–330. https://doi.org/10.1007/978-3-030-36248-5_16
9. Hernández-Montiel, L. G., Chiquito Contreras, C. J., Murillo Amador, B., Vidal Hernández, L., Quiñones Aguilar, E. E. and Chiquito Contreras, R. G. (2017). Efficiency of two inoculation methods of Pseudomonas putida on growth and yield of tomato plants. J Soil Sci Plant Nutr. 17(4): 1003–1012. https://doi.org/10.4067/s0718-95162017000400012
10. Msimbira, L. A. and Smith, D. L. (2020). The Roles of Plant Growth Promoting Microbes in Enhancing Plant Tolerance to Acidity and Alkalinity Stresses. Front Sustainable Food Syst. 4: e00106. https://doi.org/10.3389/fsufs.2020.00106
11. Venugopalan, V., Challabathula, D. and Bakka, K. (2023). Emerging Roles of Plant Growth Promoting Rhizobacteria in Salt Stress Alleviation: Applications in Sustainable Agriculture. In: Mathur, P., Kapoor, R., Roy, S. (eds.). Rhizosphere Biology: Microbial Symbionts and Plant Health: Trends and Applications for Changing Climate Springer. 397–437. https://doi.org/10.1007/978-981-99-0030-5_15
12. Taj, Z. and Challabathula, D. (2021). Protection of Photosynthesis by Halotolerant Staphylococcus sciuri ET101 in Tomato (Lycoperiscon esculentum) and Rice (Oryza sativa) Plants During Salinity Stress: Possible Interplay Between Carboxylation and Oxygenation in Stress Mitigation. Front Microbiol. 11: e547750. https://doi.org/10.3389/fmicb.2020.547750
