I Plate-based Assay for Studying How Fungal Volatile Compounds (VCs) Affect Plant Growth and Development and the Identification of VCs via SPME-GC-MS

Materials and Reagents

1. Surgical blades #10 and #11
2. Parafilm (Bemis, catalog number: PM-99)
3. Paper towel
4. 10 µl and 1,000 µl micropipette tips
5. 100 x 15 mm I plate (VWR, catalog number: 25384-310)
6. 100 x 100 mm square plate (VWR, catalog number: 10799-140)
7. 100 x 15 mm (VWR, catalog number: 25384-302) and 60 x 15 mm (VWR, catalog number: 25384-092) Petri plates
8. 1.7 ml microcentrifuge tube (VWR, catalog number: 87003-294)
9. 25 ml serological pipette (VWR, catalog number: 89130-900)
10. Filter unit with 0.2 µM cellulose membrane (Nalgene, catalog number: 121-0020)
11. 1.5 ml sample vial (Shimadzu, catalog number: 221-34274-91), white cap with septum
12. V. dahliae strains PD322 and PD413 (conidial suspension in 20% glycerol and stored at -80 °C)
13. A. thaliana ecotype Col-0 seeds (Lehle Seed Co.)
14. Sterile MilliQ water
15. Murashige and Skoog (MS) basal medium (Sigma-Aldrich, catalog number: M0404-10L)
16. Sucrose (Alfa Aesar, catalog number: A15583)
17. Granulated agar (Difco, catalog number: 214530)
18. Potato dextrose agar (PDA) (Difco, catalog number: 213400)
19. 200 proof ethanol (KOPTEC, catalog number: 64-17-5)
20. 6% sodium hypochlorite (CLOROX)
21. n-Hexane (EMSURE, catalog number: 1043744000)
22. C₇-C₃₀ saturated alkanes (Sigma-Aldrich, catalog number: 49451-U)
23. 99.99% pure helium gas
24. 0.5x PDA medium (see Recipes)
25. MS agar medium (see Recipes)


Equipment

1. Pyrex glass bottle
2. 10 µl and 1,000 µl micropipettes
3. Scalpel
4. Forceps
5. Cork borer (5 mm in diameter)
6. SPME fiber holder (Supelco, catalog number: 57330-U)
7. 15 ml clear glass vial (Supelco, catalog number: 27159), screw cap with PTFE/silicone septum
8. SPME fiber assembly with 50/30 µm DVB/CAR/PDMS fiber coating (Supelco, catalog number: 57328-U)
9. Electric pipette controller (Drummond Scientific Co., catalog number: 4-000-110-TC)
10. Vortex (VWR, model: Genie 2)
11. Table-top centrifuge (Eppendorf, model: 5417C)
12. Table-top shaker (VWR, catalog number: 57018-754)
13. Analytical balance (Mettler Toledo, model: AE-100)
14. Dissecting microscope (Zeiss, model: Stemi 2000-C)
15. Incubator (Sheldon Manufacturing, model: 1510E)

16. Plant growth chamber (Conviron, model: CMP5090)
17. Flexible-arm electrode holder (Mettler Toledo, catalog number: 30266628)
18. GC-MS system (Shimadzu, model: GCMS-QP2010 ultra) equipped with AOC-20i auto injector (Shimadzu, catalog number: 221-72315-48)
19. Rtx-Wax capillary (60 m, 0.25 mm ID and 0.25 μm d_f) column (Restek, catalog number: 12426)

20. 4 °C refrigerator
21. Autoclave


Software

1. ImageJ (version 1.52a)
2. GC-MS Solution (Shimadzu, version 2.72), a package supporting GC-MS real-time and post-run analyses
3. National Institute of Standards and Technology (NIST) Mass spectral library (Shimadzu, version 11)


Procedure

1. I plate assay (Figure 1)

   1. Use a sterile 10 µl pipette tip to streak V. dahliae stock on 0.5x PDA (Recipe 1) plate in a zigzag pattern and incubate at 22 °C for 10 days.
   2. Surface sterilize A. thaliana seeds as follows:

      1. Add 1 ml 95% ethanol to a 1.7 ml microcentrifuge tube containing seeds, vortex, and incubate for 1 min.
      2. After removing ethanol, wash once with sterile MilliQ water and discard the water.
      3. Add 1 ml 6% sodium hypochlorite solution, vortex, and incubate for 15 min by shaking at 100 rpm.
      4. Wash twice with sterile MilliQ water after removing the sodium hypochlorite solution.
      5. Incubate seeds in 1 ml sterile MilliQ water at 4 °C in darkness for 3 days.
   3. Prepare square plates with MS agar (Recipe 2) and slice the medium into 10 x 10 mm pieces using a sterilized scalpel with blade #10.

   4. Hold one seed at the tip of a 10 µl micropipette using suction and then release the seed onto each agar piece. Seal the plate with two layers of Parafilm and place in a plant growth chamber set at 22 °C, 12 h light (4,500 lux, 60 μmol photons m^-2 s^-1), and 60% relative humidity for 7 days.
   5. Prepare I plate by adding 8 ml MS agar to one compartment and 8 ml 0.5x PDA to the other compartment.
   6. Transfer five A. thaliana seedlings (similar in size and growth stage) along with attached agar piece to the MS side of I plate using a sterilized scalpel with blade #10.
   7. Use a heat-sterilized cork borer to generate culture plugs along the actively growing margin of V. dahliae culture and place one plug (upside down) to the far end of the PDA side of I plate using a sterilized scalpel with blade #11.
   8. Seal the inoculated I plate with two layers of Parafilm and place in a plant growth chamber for a designated amount of time for each experiment (see Li et al., 2018b for specific examples).


   Figure 1. Workflow of the I plate-based assay


2. Extraction of VCs produced by V. dahliae (Figure 2)

   1. Inoculate a plug of V. dahliae culture on 8 ml PDA slant in a 15 ml clear glass vial. Seal the vial with Parafilm.
   2. Incubate at 22 °C until the culture fully covers the surface of PDA slant, which typically takes 8 days.
   3. Replace Parafilm with a screw cap containing PTFE/silicone septum and incubate for one day.

   4. Condition the SPME fiber before VC extraction by placing the SPME needle into the GC injection port set at 230 °C for 1 h.
   5. Insert the conditioned SPME fiber in the injection port and starting the GC temperature program shown in Table 1. Desorb the fiber for 5 min in the injection port. Retract the fiber and remove the needle after 5 min and check resulting chromatograms when the program is completed. The intensity of background peaks (= blank sample) should be very low. Otherwise, repeat the desorption of the fiber.
   6. Extract VCs for 1 h by leaving the SPME fiber in the headspace of sampling vial. Use a flexible-arm electrode holder to lock the position of the SPME fiber holder so that the insertion depth of fiber is uniform for all extractions.


   Figure 2. Workflow of volatile compound extraction

   Table 1. Conditions for gas chromatography-mass spectrometry analysis



3. GC-MS analysis of extracted VCs (Figure 3)

   1. Analyze the extracted VCs using a GC-MS system (manual injection mode, Figure 3A) by following the conditions described in Table 1. Insert the SPME needle into the GC injection port immediately after retracting it from each sampling vial. Desorb VCs bound to the SPME fiber for 5 min. An Rtx-Wax capillary column is used as it exhibits better retention and separation of polar VCs.
   2. Place the fiber in the GC injection port for 20 min for desorption before extracting another sample of VCs.
   3. Analyze C₇-C₃₀ saturated alkane standards using the automatic sample injection mode (Figure 3B). Connect the AOC-20i auto injector to the GC injection port. Place a 1.5 ml sample vial containing 0.5 ml solution of standards (1:50 dilution with n-hexane) on the rack of the auto injector. Inject 1 μl solution into the GC-MS system and analyze using the same column and conditions (Table 1).




   Figure 3. Gas chromatography-mass spectrometry analysis. A. Extracted volatile compounds (VCs) from V. dahliae were analyzed via the manual injection mode. B. Alkane standards were analyzed using the automatic sample injection mode.


Data analysis

1. Assessment of root growth and development after individual VC treatments

   1. After co-cultivation, use forceps to gently pull A. thaliana seedlings from the medium without damaging their roots.
   2. Remove excess moisture on the roots using a paper towel.

   3. Detaching roots from the shoot using forceps, weigh the roots immediately using an analytical balance.
   4. Mount the roots on a flat surface (e.g., 100 x 15 mm Petri plate) and add 3 ml water on them.
   5. Gently spread the roots using forceps so that the primary and lateral roots do not overlap.
   6. Use the bottom of 60 x 15 mm Petri plate to flatten the roots (Figure 4A) for subsequent measurements:

      1. Count the number of lateral roots, including all branches, under a dissecting microscope.
      2. Take pictures of the roots and import them to ImageJ. Follow the instruction in ImageJ to measure the primary root length (Figure 4B).
   7. Calculate the lateral root density of each sample by dividing the number of lateral roots by the primary root length.


      Figure 4. Analysis of A. thaliana roots after treating with volatile compounds produced by V. dahliae. A. Flattened A. thaliana roots by pressing with a 60 x 15 mm Petri plate. B. Snapshot of ImageJ data used to measure the length of the primary root (indicated by the yellow line) after VC treatment. The start and end of the primary root were indicated using red arrows.



2. Identification of individual compounds

   1. Peak finding, peak integration, and retention time correction were performed using the post-run analysis software in the GC-MS Solution package.
   2. The putative identity of each compound (peak) was determined using the following methods.

      1. Compare resulting mass spectral profiles with reference data archived in the NIST mass spectral library (version 11). The top hit(s) with match factors ≥ 90% were put on a “positive list” of tentatively identified compounds.
      2. Calculate the retention index (RI) of each compound using the following equation (for temperature programmed chromatography) (Kováts, 1958).


         where,
         x = Unknown compound in the sample
         n = The number of carbons in the alkane preceding the unknown compound
         N = The number of carbons in the alkane following the unknown compound
         Tx = The retention time of the unknown compound
         Tn = The retention time of the preceding alkane
         TN = The retention time of the following alkane

      The experimentally obtained RI of each peak was compared to those in the NIST Chemistry WebBook (https://webbook.nist.gov, using polar columns). For positive confirmation of identity, a maximum relative deviation of ± 2% from published values was used (Stoppacher et al., 2010).

Notes

1. The I plate assay may not be suitable for studying the effect of VCs produced by fungi that grow rapidly, as fungal mycelia may grow over the central divider of I plate and contaminate the MS medium. We removed agar strips from both sides of the divider of I plate to prevent this kind of contamination when we studied fungi that grow faster than V. dahliae (Bitas et al., 2015). However, for fungi like Trichoderma, this measure was not sufficient (Li et al., 2018a).
2. Due to the limited space of I plate, only small plants (e.g., A. thaliana and Nicotiana benthamiana) in their early growth stage are suitable for this assay.
3. Under the growth conditions used, growth promoting effect on A. thaliana becomes noticeable as early as after 7 days of co-cultivation with V. dahliae (Li et al., 2018b).
4. Because A. thaliana starts to initiate inflorescence development after 14 days of co-cultivation, we recommend that the duration of co-cultivation should not exceed 14 days.
5. Here, we only described how to analyze the root growth and development after VC exposure. Other traits of VC-exposed plants, such as shoot weight, chlorophyll content, physiological and molecular changes, can also be analyzed (e.g., Zhang et al., 2007 and 2008; Li et al., 2018b).
6. Several SPME fibers and GC columns may need to be evaluated to optimize the scheme for VC extraction and analysis. In our research, the DVB/CAR/PDMS 50/30 µm fiber coating extracted the largest number of VCs, and the Rtx-Wax capillary column enabled better separation of extracted VCs than the DB-5 column.
7. Analysis of VCs extracted from uninoculated PDA slant is necessary to exclude VCs derived from the medium and the environment.


Recipes

1. 0.5x PDA medium (1 L)
   19.5 g PDA
   Pour the autoclaved medium after cooling it down to 50 °C
2. MS agar medium (1 L)
   4.5 g MS and 7.5 g agar
   Add 5 ml 50% (w/v) sucrose (filter sterilized) after cooling down the autoclaved medium to 50 °C
   Mix well before pouring
