Endoscopic Collection and Analysis of Gastric Fluid DNA: A Liquid Biopsy Methodology for Tumor Biomarker Discovery

Materials and reagents

Biological materials

1. Gastric fluid and gastric fluid DNA (gfDNA) collected from patients undergoing upper endoscopic examinations

Reagents

1. pH measuring stripes (e.g., Sigma-Aldrich, catalog number: P4786-100EA)

2. Sodium hydroxide, 1 N solution (Sigma-Aldrich, catalog number: S2770)

3. Cell lysis solution (QIAGEN, Gentra Puregene Blood Kit, catalog number: 158467)

4. Proteinase K (Sigma-Aldrich, catalog number: 1.24568)

5. Phenol:chloroform:isoamyl alcohol (25:24:1) (Sigma-Aldrich, catalog number: P2069)

6. Chloroform (Sigma-Aldrich, catalog number: C2432)

7. Ethanol 100% (Merck, CAS 64-17-5)

8. Ethanol 70% (prepared in molecular biology–grade water) (Merck, CAS 64-17-5)

9. Sodium acetate (prepared in molecular biology–grade water) (Sigma-Aldrich, catalog number: S2889)

10. Water, molecular biology grade (Thermo Fisher Scientific, catalog number: 10977-015)

11. Qubit^TM dsDNA High Sensitivity Assay kit (Thermo Fisher Scientific, catalog number: Q32854)

Solutions

1. Sodium acetate (see Recipes)

Recipes

1. Sodium acetate, 3 M, pH 5.2

Filter sterilize (0.22 μm). Store at room temperature (RT) for 7 days or at 4 °C for up to 12 months.

Laboratory supplies

1. Microcentrifuge tubes, 2.0 mL, DNase/RNase-free

2. Microcentrifuge tubes, 1.5 mL, DNase/RNase-free

3. Sterile pipette tips (10, 200, 1,000 μL)

4. Serological pipettes (5 and 10 mL, sterile)

5. Cryovials (DNase/RNase-free)

6. Cryoboxes

7. Glass beakers (≥500 mL)

8. Qubit^TM assay tubes (Thermo Fisher Scientific)

9. Disposable gloves (nitrile, powder-free)

10. Parafilm^® M sealing film (Heathrow Scientific, or similar)

11. Micropipettes of variable volumes

Equipment

1. Standard upper gastrointestinal endoscope (gastroscope) and ancillary clinical equipment for visualization, air insufflation, water irrigation, and suction/vacuum system, as available

2. -20 °C freezer

3. -80 °C ultra-low freezer

4. Microcentrifuge (refrigerated)

5. Vortex mixer

6. Thermoblock

7. Water bath

8. Qubit^TM Fluorometer (Thermo Fisher Scientific)

Software and datasets

1. Microsoft Excel (Microsoft, https://products.office.com/en-us/excel) or similar, for general data organization

2. R software (https://www.R-project.org/), including the maxstat package (maxstat.test function) for statistical analyses

Procedure

An overview of the entire protocol workflow is shown in Figure 1.

Figure 1. Workflow of the protocol from gastric fluid collection to DNA quantification. (A) Endoscopic examination. (B) Preparation for gastric fluid collection. (C) Gastric fluid collection. (D) Sample storage at -20 °C followed by long-term storage at -80 °C. (E) DNA extraction from gastric fluid. (F) DNA quantification.

A. Endoscopic examination

As usual and customary for upper endoscopic examination, all subjects were fasting for 8–12 h. Best-practice EGD requires a minimum examination time of 7 min, adequate gastric distension, and a systematic screening protocol for the stomach [10]. This includes antegrade inspection of four quadrants of the antrum, body, and middle-upper body, followed by retroflexed inspection of four quadrants of the fundus and cardia and three quadrants of the middle-upper body and incisura to eliminate blind spots. As usual, in some endoscopy services (though the routine may vary by institution), a 1-mL solution of 75 mg of simethicone (or similar anti-foam agent) is administered orally a few minutes before the procedure. Because the volume is small and the same preparation is given to all human subjects undergoing EGD, any effect on gfDNA concentration and composition is likely consistent across groups and therefore bias-free.

B. Preparation for the gastric fluid collection

1. The endoscope intended to be used for the collection of gastric fluid should be rinsed with distilled water:

a. Place the tip of the endoscope into a beaker containing approximately 500 mL of distilled water.

b. Use a vacuum pump to drain the distilled water from the beaker into the water collection tank.

c. Discard the water from the collection tank.

d. Rinse both the collection tank and the beaker with distilled water.

f. Operate the vacuum pump to drain the inner channel of the endoscope.

2. If microbiome studies are planned, collect 1 mL of the rinse water as a negative control. Samples should be initially stored at -20 °C for 3–6 h and then transferred to -80 °C for long-term storage. An overview of the containers and connections is given in Figures 2 and 3.

Figure 2. Components of the gastric fluid collection container. (A) Perfluoroalkoxy alkane (PFA) screw cap. (B) Glass bottle (250 mL). (C) Polytetrafluoroethylene (PTFE) screw joints. (D) PFA hose connector. (E) PTFE thread adaptor. (F) PTFE tubing. Examples given from connectors sold by www.bola.de.

Figure 3. Rinsing of the internal endoscope channel with distilled water. (A) Endoscope. (B) A beaker with 500 mL of distilled water. (C) Vacuum pump with collection tank.

C. Gastric fluid collection

1. Attach the gastric fluid collection container to the endoscope.

2. Connect the collection container to the vacuum pump.

3. At the beginning of the endoscopic examination, the operator drains gastric fluid into the collection container.

4. After collection, disconnect the container from both the endoscope and the vacuum pump. This arrangement is illustrated in Figure 4.

Figure 4. Organization of the gastric fluid collection system during endoscopy. (A) The gastric fluid collecting container is connected to the endoscope. (B) Gastric fluid collecting container. (C) The gastric fluid collecting container is connected to the vacuum pump.

D. Sample storage

1. The pH of gastric fluid varies. In healthy individuals, fasting gastric fluid is typically highly acidic, with a pH of ~1.5–2.0; however, in patients with gastric diseases, especially gastric cancer, the pH may be elevated, and the fluid may be acidic, neutral, or non-acidic. Acidic conditions may lead to DNA depurination and hydrolysis. To limit these processes, immediately after collection, measure and neutralize the samples of gastric fluid pH using pH measuring stripes and carefully adding a few microliters of the 1N NaOH solution.

2. Prepare aliquots of neutralized gastric fluid samples (800 μL) in 2.0 mL tubes. The number of aliquots depends on the volume of gastric fluid recovered, the aim of the study, and freezer space available. Store tubes at -20 °C for initial freezing.

3. After 3–6 h, transfer the samples to -80 °C for long-term storage.

4. Maintain samples continuously frozen at -80 °C throughout the entire storage period.

5. As per the best practices, always avoid freeze/thaw cycles during storage and/or sample handling.

E. DNA extraction from gastric fluid

1. Add 500 μL of cell lysis solution to 800 μL of a gastric fluid aliquot.

2. Add 15 μL of Proteinase K (20 μg/μL).

3. Incubate at 55 °C under agitation (300 rpm) for approximately 1 h or until complete lysis is achieved (a water bath may be used). For highly viscous samples, incubation may be extended overnight (up to 18 h). Complete lysis is indicated by the absence of visible particulate material and a homogeneous lysate.

4. Add 500 μL of phenol:chloroform:isoamyl alcohol (25:24:1, v/v/v) to the lysate.

5. Vortex for 1 min until the solution becomes milky.

6. Centrifuge at ~16,000× g for 10 min at RT.

7. Transfer up to 950 μL of the upper aqueous phase to a new 2.0 mL tube.

8. Add 500 μL of phenol:chloroform:isoamyl alcohol (25:24:1, v/v/v).

9. Gently vortex until the solution becomes milky.

10. Centrifuge at ~16,000× g for 10 min at RT.

11. Add 500 μL of chloroform directly to the tube.

12. Repeat step E9.

13. Centrifuge at ~16,000× g for 10 min at room temperature.

14. Transfer up to 950 μL of the upper aqueous phase to a new 2.0 mL tube.

15. Add 800 μL of cold 100% ethanol and 10% volume (80 μL) of 3 M sodium acetate.

16. Mix thoroughly by inversion or brief vortexing.

17. Incubate at -20 °C for at least 1 h or overnight. This step can be skipped if a visible DNA precipitate is already present.

18. Centrifuge at ~20,000× g for 30 min at 4 °C.

19. Carefully remove the supernatant by inversion.

20. Add 1 mL of ice-cold 70% ethanol.

21. Gently detach the pellet from the bottom of the tube during the first wash (side-vortexing may help).

22. Centrifuge at ~20,000× g for 5 min at 4 °C.

23. Repeat the washing steps (E20–21).

24. Centrifuge at ~20,000× g for 3 min at 4 °C.

25. Remove the supernatant carefully by inversion.

26. Perform a quick spin and remove residual ethanol with a pipette.

27. Dry the pellet at room temperature or 42 °C until no ethanol remains.

28. Keep the tube open during drying.

29. Resuspend the pellet in 100 μL of nuclease-free water.

30. Homogenize with a pipette.

31. Incubate at 55 °C for 10 min in a thermoblock.

32. If the pellet is not fully dissolved, incubate overnight at 4 °C.

33. Measure DNA concentration by using a Qubit High Sensitivity DNA assay.

Note: These steps are summarized in Figure 5.

Figure 5. DNA extraction steps from gastric fluid

F. DNA quantification

1. Add 198 μL of Qubit working solution to an assay tube.

2. Add 2 μL of the DNA sample.

3. Mix by gently vortexing or pipetting, avoiding the formation of bubbles.

4. Keep the samples at room temperature for 2 min before DNA quantification.

Data analysis

1. Calculate the average of the gfDNA replicate quantification values.

2. Organize the data in Microsoft Excel and import the dataset into R.

3. Install and load the maxstat package, which contains the maxstat.test function: install.packages("maxstat") and library(maxstat).

4. Use the maxstat.test function to determine the optimal gfDNA cutoff value based on your own dataset. We recommend an independent evaluation of the results using maxstat.test, followed by the log-rank test to determine the optimal cutoff value.

5. As a reference, the gfDNA cutoff value obtained in our study to indicate prognosis (1.28 ng/μL) was derived from DNA extracted from 800 μL of gastric fluid and resuspended in 100 μL, as described in this protocol.

6. In our report [8], individuals with gfDNA concentrations >1.28 ng/μL showed a better prognosis.

Validation of protocol

This protocol has been applied and validated in:

Cadoná et al. [8]. Endoscopic liquid biopsies of gastric fluid in a large human patient cohort reveal DNA content as a candidate tumor biomarker in gastric cancer. eLife. 2025 Dec 16;14:RP107103. doi: 10.7554/eLife.107103. PMID: 41400466; PMCID: PMC12707811.

General notes and troubleshooting

General notes

1. Gastric fluid DNA represents total DNA available and does not distinguish between cellular origins.

2. In some settings, DNA quantity will be below the detection limit.

3. The volume of gastric fluids in patients will vary markedly. In a small fraction of patients, no gastric fluid is observed during endoscopy. In these cases, DNA for microbiome and tumor-DNA analysis can still be obtained by rinsing the stomach with 10–20 mL of saline, which is then aspirated and processed identically to routine gastric fluid. However, gfDNA concentration comparisons between rinsed and non-rinsed (“native”) gastric fluid samples are confounded by dilution and must be interpreted with great caution.

Troubleshooting

Problem 1: Low DNA quantity.

Possible cause: Insufficient starting volume of gastric fluid, which inherently contains low concentrations of shed epithelial cells and microbial DNA due to the harsh, degradative environment of the stomach.

Solutions: Increase the input volume by pooling two or more aliquots of gastric fluid and combining them prior to lysis, or alternatively, process multiple aliquots in parallel through lysis and binding steps and combine the resulting DNA during the final ethanol precipitation or elution step. Additionally, consider extending the proteinase K digestion time to improve cell lysis and maximize DNA release, particularly if the sample is viscous or contains mucin. Prolonged incubation at 56 °C with intermittent vortexing can significantly enhance yields from difficult specimens. Final DNA concentration should always consider the total volume of gastric fluids used during extraction.

Problem 2: Inconsistent quantification (high variability between replicate readings).

Possible causes: Pipetting errors, including inaccurate delivery volumes, failure to mix samples thoroughly before aliquoting, or using tips that are not properly calibrated or pre-wetted for viscous solutions. Other contributing factors may include incomplete dissolution of the DNA pellet, residual ethanol or salts interfering with absorbance measurements, or using an improperly blanked spectrophotometer.

Solutions: Ensure all samples are fully resuspended by incubating at 55 °C for 5–10 min with intermittent vortexing and brief centrifugation to collect the liquid at the bottom of the tube. Always measure each sample in technical triplicates from independent aliquots and record the average while discarding any outlier that deviates more than 10% from the mean. Use the average value for subsequent analyses. Additionally, verify that the blank is measured using the identical buffer or water used for resuspension. If variability persists, check pipette calibration and replace tips with low-retention versions to ensure consistent delivery.

Problem 3: Degradation during storage.

Possible causes: Delayed freezing or repeated freeze/thaw cycles.

Solutions: To preserve sample integrity, gastric fluid should be processed or frozen as rapidly as possible after collection—ideally within 30 min—by snap-freezing in liquid nitrogen or a dry ice–ethanol bath before transfer to storage conditions. For short-term storage (up to a few weeks), samples may be kept at -20 °C, but for long-term preservation (months to years), they should be transferred to -80 °C to minimize enzymatic activity and nucleic acid hydrolysis. To completely avoid repeated freeze/thaw cycles, divide the sample into single-use aliquots immediately upon collection, ensuring that each aliquot contains sufficient volume for one complete extraction and that aliquots are not refrozen once thawed. Additionally, consider adding a nuclease inhibitor (e.g., EDTA to a final concentration of 10 mM) or a commercial preservation buffer (e.g., RNAlater or DNA/RNA Shield) prior to freezing, particularly if samples will be transported or stored for extended periods before processing. When thawing aliquots for extraction, do so rapidly on ice or at 4 °C and process them promptly without prolonged exposure to room temperature.

Problem 4: No DNA pellet is visible after precipitation.

Possible causes: Low DNA concentration, resulting in a transparent or invisible pellet, or pellet dislodgement during removal of supernatant or ethanol wash steps.

Solutions: Do not assume the DNA is lost; proceed with the 70% ethanol wash as usual, even if no pellet is visible. When removing supernatant, mark the side of the tube where the pellet should be (the outer side of the centrifuge rotor) and pipette slowly from the opposite side to avoid disturbing an invisible pellet. Add the 70% ethanol gently down the side of the tube without vortexing or vigorous pipetting to prevent dislodging the pellet. After washing and drying, resuspend the DNA in the smallest practical volume (e.g., 10–20 μL) of nuclease-free water.

Problem 5: DNA contamination with phenol or ethanol (evidenced by abnormal A₂₆₀/A₂₈₀ or A₂₆₀/A₂₃₀ ratios).

Possible cause: Incomplete removal of the organic phase during phenol–chloroform extraction.

Solutions: Carefully remove the upper aqueous phase without disturbing the interphase or lower organic layer—using a fine-tipped pipette and leaving a small margin of safety (e.g., 10–20 μL of aqueous phase behind) is preferable to inadvertently transferring phenol. Performing a second chloroform extraction (without phenol) can help eliminate any residual phenol carried over from the first extraction. For ethanol contamination, after the 70% ethanol wash, remove as much supernatant as possible using a fine pipette, then air-dry the pellet at room temperature for 10–20 min until no visible moisture remains and the pellet appears slightly translucent or glassy; alternatively, use a speed-vac or gentle heating at 37 °C for 5–10 min to expedite drying, but avoid overdrying as this makes DNA difficult to redissolve. Also, measure the A_260/230 ratio, as values below 1.8 indicate phenol or ethanol carryover, while values above 2.2 may suggest residual ethanol.

Acknowledgments

Funding sources that supported the work: Fundação de Amparo à Pesquisa do Estado de São Paulo (FAPESP), Brazil (2014/26897-0, 2018/14267-2, 2018/02972-3; PI: E.D.-N.); Science and Technology Department of the Ministry of Health (DECIT, PRONON, SIPAR), Brazil (2500.035-167/2015-23; PI: E.D.-N.). RP and WA received research awards and support from the Levy-Longenbaugh Donor-Advised Fund.

This protocol was originally described and validated in [8] and is derived from the original research described in [5].

We thank Dr. Alexander Frankell (Early Cancer Institute, University of Cambridge & Francis Crick Institute, London, UK) and Dr. Rebecca Fitzgerald (Early Cancer Institute, University of Cambridge, Cambridge, UK) for the critical review of this manuscript.

Author contributions

Specific contributions of each author:

Conceptualization and Experimental Design: F.C.C., A.G.P., T.F.B., I.T.d.S., D.N.N., E.D.-N. Performing experiments: F.C.C., A.G.P., T.F.B., I.T.d.S., D.N.N., E.D.-N. Data Analysis: F.C.C., A.G.P., T.B., I.T.d.S., H.I., L.W., R.P., W.A., D.N.N., E.D.-N. Original Draft Writing: F.C.C., E.D.-N. Draft Review & Editing: All authors. Funding Acquisition: R.P., W.A., D.N.N., E.D.-N. Overall Supervision: D.N.N., E.D.-N.

Competing interests

R.P. and W.A. are founders and equity shareholders of PhageNova Bio. R.P. is the Chief Scientific Officer and serves as a paid consultant for PhageNova Bio. R.P. and W.A. are founders and equity shareholders and serve as paid consultants for MBrace Therapeutics. D.N.N and E.D.-N. serve as paid consultants for MBrace Therapeutics. W.A. and R.P. have Sponsored Research Agreements in place with both PhageNova Bio and MBrace Therapeutics. All these arrangements are managed in accordance with the established institutional conflict-of-interest policies of the respective institutions. These conflicts of interest fall entirely outside of the scope of the current study. Other authors declare that no conflicts of interest exist.

Ethical considerations

Sample collection was performed following written informed consent signed by all patients or their legal guardians. The study was evaluated and approved (protocol #2134/15) by the Clinical Research Committee and the Ethics Research Committee of the A. C. Camargo Cancer Center, São Paulo, SP, Brazil.
