Simple Methods for Screening and Statistical Analysis of Leaf Epidermal Cells in Dicotyledonous Plants

Plant Science > Plant cell biology > Cell structure
Authors: Jian-Jun Tao
Jian-Jun TaoAffiliation: State Key Lab of Plant Genomics, Institute of Genetics and Developmental Biology, Chinese Academy of Sciences, Beijing, China
Bio-protocol author page: a3467
Shou-Yi Chen
Shou-Yi ChenAffiliation: State Key Lab of Plant Genomics, Institute of Genetics and Developmental Biology, Chinese Academy of Sciences, Beijing, China
Bio-protocol author page: a3468
 and Jin-Song Zhang
Jin-Song ZhangAffiliation: State Key Lab of Plant Genomics, Institute of Genetics and Developmental Biology, Chinese Academy of Sciences, Beijing, China
For correspondence: jszhang@genetics.ac.cn
Bio-protocol author page: a3469
Vol 6, Iss 17, 9/5/2016, 431 views, 0 Q&A, How to cite
DOI: http://dx.doi.org/10.21769/BioProtoc.1916

[Abstract] Leaf epidermal cell size and number are positively correlated to leaf area. Stomata are specialized epidermal cells vital for gas exchange and water transpiration. So, observation and statistical analysis of the leaf epidermal cells is valuable for study of leaf development and response to environmental stimulus. The classical method is using the scanning electron microscope (SEM), which is an expensive and time-consuming method, thus makes the large-scale screening of epidermis impractical. Here we provide simple but effective methods (agarose-based epidermal imprinting and tape-based epidermis tearing) for solving this problem without using the SEM.

Keywords: Epidermal cell, Stomata, Epidermal imprinting, Epidermis tearing, ImageJ

Materials and Reagents

  1. Glass slide (Leica, model: 3809299)

  2. Scotch tape (1/2") (3M, Scotch®, model: 600)

  3. Tobacco (one month old) and soybean seedlings (two weeks old)
  4. Distilled water

  5. Low melting point agarose (Thermo Fisher Scientific, InvitrogenTM, catalog number: 16520-050)
  6. 3% agarose solution (see Recipes)

Equipment

  1. Thermostatic water bath (40 °C)
  2. Pointed tweezer (Tweezerman, model: 4091833)
  3. Refrigerator (4 °C) (Haier, model: HT18TS77SP)
  4. Optical microscope (Olympus, model: BX51)
  5. Objective used on microscope (Olympus, model: UPlanFI)

Software

  1. ImageJ (version 1.38x or above)

Procedure

  1. Leaves for screening of epidermis are photographed by digital camera (Figure 1). The total Leaf Area (LA) is measured using ImageJ. For measuring area using ImageJ, use the straight lines tool to create a line selection corresponding to the scale ruler, and enter that distance in the Analyze > Set Scale dialog box to set the scale. Then use the Polygon selections tool to encircle the target region, and press the M key to measure the area.


    Figure 1. A photograph of leaves used for screening of epidermis. Leaves with a scale ruler were photographed by digital camera. Leaf area was measured using ImageJ.

  2. For statistical analysis of leaf epidermis, leaf is divided into several parts along leaf veins (Figure 2), and the area of each leaf part (ALP) is measured using ImageJ.


    Figure 2. Leaf partition for screening of epidermis. For measuring the epidermal cell size and number, leaf (tobacco) was divided into several parts (partitioned by yellow lines), and the area of each leaf part (ALP) was measured using ImageJ. Blue cycles indicate the leaf pieces selected for observing epidermis. Arrow indicates the central part selected for screening of stomata. Bar = 2 cm.

  3. One to three leaf pieces (must be uniformly distributed) in each leaf part are selected for observing epidermis using the following methods (Figure 2).

  4. For observing fragile and less hairy leaves (such as tobacco), the agarose-based epidermal imprinting method is carried out as follows:
    1. 3% agarose solution is melted thoroughly in a boiling water bath (about 10 min for 50 ml solution) or in a microwave (30 sec for 50 ml agarose solution under 1,000 W) and kept in a 40 °C water bath.

    2. Agarose is laid on the surface of a clean glass slide with a pipette to form a thin layer (about 1 mm thick) (Video 1).

      Video 1. Sample preparation for epidermal imprinting onto agarose

      To play the video, you need to install a newer version of Adobe Flash Player.

      Get Adobe Flash Player



    3. Leaf blade to be observed is quickly and gently laid on the agarose layer (Video 1).
    4. Put the slide immediately at 4 °C for 3 min in a refrigerator.
    5. The leaf blade is carefully peeled off using a pointed tweezer (Video 2).
    6. The specimen is observed and photographed under the optical microscope (Figure 3).

    Video 2. Demonstration of how to peel off leaf blade after imprinting

    To play the video, you need to install a newer version of Adobe Flash Player.

    Get Adobe Flash Player



  5. For observing hairy leaves (such as soybean), the tape-based epidermis tearing method is carried out as follows:
    1. Scotch tape is cut to pieces (about 0.3 x 0.3 cm).

    2. Adhere a tape piece tightly to the leaf blade with proper pressure but avoid crushing the epidermis (Video 3).

      Video 3. Sample preparation for tape-based epidermis tearing method

      To play the video, you need to install a newer version of Adobe Flash Player.

      Get Adobe Flash Player



    3. Tear off the strip carefully from one side using a pointed tweezer (the epidermis is sticking to the tape) (Video 3).

    4. If massive mesophyll cells adhered to the epidermis, they can be gently scraped off from one side using a tweezer.

    5. The epidermis strip is immersed in distilled water on a glass slide, avoiding bubbles (Video 3).

    6. The specimen is observed and photographed under the optical microscope (Figure 4).
  6. The average cell size of each leaf is measured and calculated as follows:
    1. Three regions (50-100 cells) in micrographs of each leaf piece are selected using the Polygon selections tool in ImageJ (Figure 3). The region area is measured, and cell number is counted.
    2. Calculate the Cell Size of each leaf Part (CSP) (divide the total area of all regions selected in each leaf part by total cell number of all regions).

    3. The average cell size (ACS) is calculated using the following formula:

      ACS=Σ CSPn x ALPn/LA
  7. The Cell Number per leaf (CN) is then calculated as follows:
    CN = LA/ACS
  8. For measuring the stomatal density and the stomatal aperture, the central part of each leaf is selected for observing epidermis using the methods described in step 4 or 5.

  9. Three regions (20-50 stomata) in micrographs are selected using the polygon selection tool in ImageJ. The region area is measured, the stomatal number is counted, and the stomatal density is calculated (dividing the stomatal number by area). The stomatal width and length are also measured using the Straight lines tool in ImageJ, and the stomatal aperture is calculated (divide the stomatal width by the stomatal length).


Representative data



Figure 3. Screening of leaf epidermal cells by agarose imprinting. Leaf (tobacco) epidermis was imprinted onto agarose and screened under the optical microscope. The polygon with yellow edges indicates a selected area for measuring the cell size of a leaf part. The black dots are marks (created using the Paintbrush Tool in ImageJ) for counting cell numbers. Bar = 200 μm.


Figure 4. Screening of leaf epidermal cells by tearing the epidermis. Leaf (soybean) epidermis was tore off using the scotch tape and screened under the optical microscope. Bar = 50 μm.

Notes

  1. Using the agarose imprinting method, the leaf blade must be flat and laid on the melting agarose very gently. Otherwise, some detail structure of the epidermis will be lost or even failed to be imprinted on the agarose.

  2. Using the epidermal tearing method, the mesophyll cells should be scraped gently from one side for one time only to avoid destroying the structure of epidermis.

  3. Young and flat leaves are better than old and rounded leaves for epidermis screening.

Recipes

  1. 3% agarose solution (50 ml)
    Add 1.5 g low melting point agarose to 50 ml distilled water
    Boil until the agarose is melted completely
    Use when the temperature is about 40 °C
    Seal and store at RT (only need melting when necessary to use)

Acknowledgments

This protocol was improved from the previously published studies (Mathur and Koncz, 1997; De Veylder et al., 2001; Tao et al., 2015). This work was supported by the National Natural Science Foundation of China (grant No.91317306) and the State Key Lab of Plant Genomics.

References

  1. De Veylder, L., Beeckman, T., Beemster, G. T., Krols, L., Terras, F., Landrieu, I., van der Schueren, E., Maes, S., Naudts, M. and Inze, D. (2001). Functional analysis of cyclin-dependent kinase inhibitors of Arabidopsis. Plant Cell 13(7): 1653-1668.
  2. Mathur, J. and Koncz, C. (1997). Method for preparation of epidermal imprints using agarose. Biotechniques 22(2): 280-282.
  3. Tao, J. J., Cao, Y. R., Chen, H. W., Wei, W., Li, Q. T., Ma, B., Zhang, W. K., Chen, S. Y. and Zhang, J. S. (2015). Tobacco translationally controlled tumor protein interacts with ethylene receptor tobacco histidine kinase1 and enhances plant growth through promotion of cell proliferation. Plant Physiol 169(1): 96-114.


How to cite this protocol: Tao, J., Chen, S. and Zhang, J. (2016). Simple Methods for Screening and Statistical Analysis of Leaf Epidermal Cells in Dicotyledonous Plants. Bio-protocol 6(17): e1916. DOI: 10.21769/BioProtoc.1916; Full Text
