Gram Stain for Intestinal Bacteria

Microbiology > Microbe-host interactions > Bacterium
Authors: Luise Goroncy
Luise GoroncyAffiliation: Department of Hematology and Oncology, University Medical Center, Freiburg, Germany
Bio-protocol author page: a2052
 and Robert Zeiser
Robert ZeiserAffiliation: Department of Hematology and Oncology, University Medical Center, Freiburg, Germany
For correspondence: robert.zeiser@uniklinik-freiburg.de
Bio-protocol author page: a2053
Vol 5, Iss 6, 3/20/2015, 2865 views, 0 Q&A
DOI: https://doi.org/10.21769/BioProtoc.1419

[Abstract] With this protocol you can perform a gram stain in paraffin embedded tissue sections.

Materials and Reagents

  1. Tissue sections (paraffin embedded, gained from mice)
  2. Paraffin (Engelbrecht, catalog number: 17932 )
  3. Xylene (VWR International, catalog number: 28975 )
  4. Ethanol (Sigma-Aldrich, catalog number: 32205 )
  5. Iodine (Merck KGaA, catalog number: 109261 )
  6. Safranin (Merck KGaA, catalog number: 109217 )
  7. Crystal violet (Merck KGaA, catalog number: 109218 )
  8. Decolorizing agent (Merck KGaA, catalog number: 110218 )
  9. 100% (v/v) ethanol (see Recipes)
  10. 96% (v/v) ethanol (see Recipes)
  11. 80% (v/v) ethanol (see Recipes)


  1. Slide


  1. Paraffin embedded 5 µm tissue sections were deparaffinized: 1 h on 58 °C, 5 x 6 min in xylene, 4 x 3 min in 100% (v/v) ethanol, 2 min in 96% (v/v) ethanol, 2 min in 80% (v/v) ethanol and 2 min in aqua dest.
  2. Tissue sections were incubated for 1.5 min with crystal violet staining reagent and washed for 30 sec under running tap water.
  3. The slide was flooded with Gram's iodine for 3 min followed by a second washing step for 20 sec with tap water.
  4. The slide was flooded with decolorizing agent for 20 sec and once again washed for 20 sec under tap water.
  5. The counterstain was safranin (1 min) which was followed by a last washing step under tap water.

Representative data

Figure 1. The intestine was stained by gram stain. Gram+ bacteria appear blue and are indicated by a red arrow.


The staining can also be performed additionally to a previous immune histological staining.


  1. 100% (v/v) ethanol
    Pure ethanol
  2. 96% (v/v) ethanol
    96 ml ethanol and 4 ml aqua dest
  3. 80% (v/v) ethanol
    80 ml ethanol and 20 ml aqua dest
    Note: The staining solutions are ready to use.


This work was supported by the DFG (ZE872/1-2 individual grant to RZ)


  1. Schwab, L., Goroncy, L., Palaniyandi, S., Gautam, S., Triantafyllopoulou, A., Mocsai, A., Reichardt, W., Karlsson, F. J., Radhakrishnan, S. V., Hanke, K., Schmitt-Graeff, A., Freudenberg, M., von Loewenich, F. D., Wolf, P., Leonhardt, F., Baxan, N., Pfeifer, D., Schmah, O., Schonle, A., Martin, S. F., Mertelsmann, R., Duyster, J., Finke, J., Prinz, M., Henneke, P., Hacker, H., Hildebrandt, G. C., Hacker, G. and Zeiser, R. (2014). Neutrophil granulocytes recruited upon translocation of intestinal bacteria enhance graft-versus-host disease via tissue damage. Nat Med 20(6): 648-654.

How to cite: Goroncy, L. and Zeiser, R. (2015). Gram Stain for Intestinal Bacteria. Bio-protocol 5(6): e1419. DOI: 10.21769/BioProtoc.1419; Full Text
