Visualization of Cell Complexity in the Filamentous Cyanobacterium Mastigocladus laminosus by Transmission Electron Microscopy (TEM)

透射电镜（TEM）法观察分析丝状蓝细菌层理鞭枝藻细胞复杂度

Dennis J. Nürnberg Dennis J. Nürnberg
GM Giulia Mastroianni
CM Conrad W. Mullineaux
GM Graham D. McPhail

发布: 2014年12月05日第4卷第23期 DOI: 10.21769/BioProtoc.1305 浏览次数: 10410

评审: Fanglian HeClaudia Catalanotti

download pdf 下载 PDF 下载 PDF
ask Q&A
引用
收藏
Cited by

参见作者原研究论文

The authors used this protocol in:

Cover of Molecular Microbiology, featuring study using the protocol.

Mar 2014

Presubmission Inquiry

实验方案合集

专注于特定技术或应用的、详细的、经过同行评审的实验方案合集

Cancer Research
Immunology
Developmental Biology
Microbiology
Neuroscience
Cell Imaging - A Special Collection for Cell Bio 2023
查看更多 more

相关实验方案

革兰阴性致病菌自然分泌的外-内膜囊泡低温透射电子显微镜观察

革兰阴性致病菌自然分泌的外-内膜囊泡低温透射电子显微镜观察

Lidia Delgado [...] Elena Mercadé

2019年09月20日 5747 阅读

利用电刺激快速检测细菌增殖

利用电刺激快速检测细菌增殖

Conor LA Edwards [...] Munehiro Asally

2020年02月05日 5389 阅读

用免疫荧光显微镜追踪金黄色葡萄球菌表面蛋白的亚细胞定位

用免疫荧光显微镜追踪金黄色葡萄球菌表面蛋白的亚细胞定位

Salvatore J. Scaffidi [...] Wenqi Yu

2021年05月20日 6431 阅读

Abstract

The cyanobacterium Mastigocladus laminosus (M. laminosus) is one of the most morphologically complex prokaryotes. It forms long chains of cells that are connected via septal junction complexes; such complexes allow diffusion of metabolites and regulators between neighboring cells. Cellular division occurs in multiple planes, resulting in the formation of true branches, and cell differentiation leads to the formation of specialized cell types for nitrogen fixation (heterocysts) and culture dispersal (hormogonia and necridia). Here, we describe a detailed protocol for the preparation of M. laminosus for TEM in order to visualize the ultrastructural properties of the organism. The presented preparation method is based on adding potassium permanganate as fixative which has been shown to increases the contrast of membranes (Luft, 1956), making it suitable for studies in cyanobacteria where the visualization of the photosynthetic membranes is important.

Keywords: Ultrastructure (超微结构) search Fischerella (侧生藻属) search Heterocyst (异形胞) search Hormogonia (段殖体) search Branching cyanobacteria (分枝蓝藻) search

Materials and Reagents

  1. Liquid culture of Mastigocladus laminosus
  2. Potassium phosphate monobasic (KH2PO4) (Thermo Fisher Scientific, catalog number: BP362 )
  3. Sodium phosphate dibasic (Na2HPO4) (Thermo Fisher Scientific, Acros Organics, catalog number: 204855000 )
  4. Glutaraldehyde (25%, EM grade) (Agar Scientific, catalog number: R1020 )
  5. Low gelling temperature agarose (Sigma-Aldrich, catalog number: A9414 )
  6. Potassium permanganate (KMnO4) (VWR International, BDH, catalog number: 296444N )
  7. 100% ethanol
  8. Propylene oxide (Agar Scientific, catalog number: R1080 )
  9. Araldite CY212 (Agar Scientific, catalog number: R1042 )
  10. Methyl nadic anhydride (MNA) (Agar Scientific, catalog number: R1083 )
  11. Dodecenylsuccinic anhydride (DDSA) (Agar Scientific, catalog number: R1052 )
  12. Benzyldimethylamine (BDMA) (Agar Scientific, catalog number: R1061 )
  13. Sodium tetraborate (borax) (Sigma-Aldrich, catalog number: 221732 )
  14. Toluidine blue (Sigma-Aldrich, catalog number: 89640 )
  15. Uranyl acetate [UO2(CH3COO)2]*2 H2O] (SPI Supplies, catalog number: 02624-AB )
  16. Lead (II) nitrate [Pb(NO3)2] (Sigma-Aldrich, catalog number: 228621 )
  17. Tri-sodium citrate (TAAB, catalog number: S011 )
  18. Sodium hydroxide (NaOH) (Sigma-Aldrich, catalog number: 221465 )
  19. 0.125 M Sørensen's phosphate buffer (PB) (see Recipes)
  20. 4% (v/v) glutaraldehyde in PB (see Recipes)
  21. 2% (w/v) low gelling temperature agarose (see Recipes)
  22. 2% (w/v) potassium permanganate (see Recipes)
  23. Araldite (see Recipes)
  24. 1% (w/v) toluidine blue (see Recipes)
  25. Uranyl acetate (see Recipes)
  26. Reynold's lead citrate stain (see Recipes)

Equipment

  1. Centrifuge
  2. Copper grids (300 mesh) (Agar Scientific, catalog number: G2740C )
  3. Dental wax
  4. Disposable plastic Pasteur pipettes
  5. Disposable polyethylene beaker
  6. Eppendorf tubes (1.5 ml)
  7. Glass or diamond knife
  8. Hotplate
  9. Light microscope
  10. Oven (60 °C)
  11. Razor blades
  12. Rotator
  13. Rubber embedding mould
  14. Sealable glass vials (7 ml)
  15. Shaker
  16. Spatula
  17. Sterilization filters (pore size: 0.22 µm)
  18. Syringe
  19. TEM (JOEL, model: JEM-1230 )
  20. Tweezers
  21. Ultramicrotome (Reichert Ultracut E)
  22. Vortexer
  23. SPI Slide-A-GridTM storage box (SPI Slide-A-GridTM, catalog number: 02450-AB )
