Synaptoneurosome Preparation from C57BL/6 Striata

Neuroscience > Cellular mechanisms > Synaptic physiology
Authors: Emma Puighermanal
Emma PuighermanalAffiliation 1: CNRS, UMR5203, Institut de Génomique Fonctionnelle, Montpellier, France
Affiliation 2: Université de Montpellier, Montpellier, France
Affiliation 3: INSERM, U1191, Montpellier, France
For correspondence: emma.puighermanal@igf.cnrs.fr
Bio-protocol author page: a2914
Anne Biever
Anne BieverAffiliation 1: CNRS, UMR5203, Institut de Génomique Fonctionnelle, Montpellier, France
Affiliation 2: Université de Montpellier, Montpellier, France
Affiliation 3: INSERM, U1191, Montpellier, France
For correspondence: anne.biever@igf.cnrs.fr
Bio-protocol author page: a2915
 and Emmanuel Valjent
Emmanuel ValjentAffiliation 1: CNRS, UMR5203, Institut de Génomique Fonctionnelle, Montpellier, France
Affiliation 2: INSERM, U1191, Montpellier, France
Affiliation 3: Université de Montpellier, Montpellier, France
Bio-protocol author page: a2916
Vol 6, Iss 4, 2/20/2016, 888 views, 0 Q&A, How to cite
DOI: https://doi.org/10.21769/BioProtoc.1735

[Abstract] Activity-dependent local mRNA translation endows synapses to remodel their structure and function (Bramham and Wells, 2007). This process is tightly controlled by the state of phosphorylation of several components of the translational machinery including initiation factors and ribosomal proteins (Buffington et al., 2014). The present protocol describes a method to prepare striatal synaptoneurosomes, from adult mice, containing both pre- and postsynaptic elements in which the level of synaptic phospho-proteins can be quantified (Biever et al., 2015).

Keywords: Synaptoneurosome, Striatum, Phospho-protein

Materials and Reagents

  1. 1 ml dounce tissue grinder (Capitol scientific, Wheaton®, catalog number: 357538)
  2. 5 ml and 60 ml syringes (BD, Plastipak, catalog number: 309647 and 300866, respectively)
  3. Nylon net filters 100 μm (Merck Millipore Corporation, catalog number: NY1H02500)
  4. Mitex membrane filter 10 μm (Merck Millipore Corporation, catalog number: LCWP02500)
  5. 1.5 ml Eppendorf tubes (Eppendorf, catalog number: 0030120086)
  6. C57BL/6 mice (≥8 weeks old, male or female) (Mus musculus)
  7. Calcium chloride (CaCl2) (Sigma-Aldrich, catalog number: C5670)
  8. Sodium chloride (NaCl) (Sigma-Aldrich, catalog number: S7653)
  9. Potassium chloride (KCl) (Sigma-Aldrich, catalog number: P9333)
  10. Potassium phosphate (KH2PO4) (Sigma-Aldrich, catalog number: P3786)
  11. Sodium bicarbonate (NaHCO3) (Sigma-Aldrich, catalog number: 71630)
  12. Magnesium chloride (MgCl2) (Sigma-Aldrich, catalog number: M8266)
  13. D-(+)-Glucose (Sigma-Aldrich, catalog number: 67528/G6728)
  14. HEPES (pH 7.4) (Sigma-Aldrich, catalog number: H3375)
  15. Sodium orthovanadate (Sigma-Aldrich, catalog number: S6508)
  16. Sodium fluorate (Sigma-Aldrich, catalog number: S7920)
  17. Sodium pyrophosphate decahydrate (Sigma-Aldrich, catalog number: 221368)
  18. Glycerol phosphate disodium salt hydrate (Sigma-Aldrich, catalog number: G6501)
  19. Aprotinin (Sigma-Aldrich, catalog number: A1153)
  20. Leupeptin hydrochloride (Sigma-Aldrich, catalog number: L0649)
  21. Pepstatin (Sigma-Aldrich, catalog number: P4265)
  22. Phenylmethylsulfonyl fluoride (Sigma-Aldrich, catalog number: 78830)
  23. Phospho-S845-GluR1 [Anti-phospho-GluR1 (Ser845) Antibody, clone EPR2148, rabbit monoclonal] (Merck Millipore Corporation, catalog number: 04-1073)
  24. Phospho-T185/Y187-ERK2 [Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204)] (Cell Signaling Technology, catalog number: 9101)
  25. Phospho-S235/236-rpS6 (Cell Signaling Technology, catalog number: 2211)
  26. Phospho-S209-eIF4E (Cell Signaling Technology, catalog number: 9741)
  27. β-actin [AC-15] (Abcam, catalog number: AB6276)
  28. Synaptoneurosome buffer (see Recipes)

Equipment

  1. Swinnex filter holder (Merck Millipore Corporation, catalog number: SX0002500)
  2. 4 ºC Eppendorf table centrifuge

Procedure

Note: This technique has been used to evaluate biochemical changes after pharmacological treatments in synaptoneurosome preparations of the striatum (Biever et al., 2015). However, the same protocol can be applied to other brain regions or after the performance of behavioral paradigms.

  1. Kill the mouse by cervical dislocation or decapitation and rapidly immerse the head in liquid nitrogen for 4 sec to rapidly cool down the brain without allowing it to freeze (this step helps for the brain dissection and to better preserve protein phosphorylation). We recommend to euthanize the mouse with physical methods such as cervical dislocation rather than using anesthetics or carbon dioxide, but this step should be adapted to local ethical committee guidelines.
  2. Remove the brain, remove the meninges, and dissect the striatum of the 2 hemispheres (≈15-20 mg) on an ice-cooled glass dish as it is shown in Video 1.

    Video 1. Striatum extraction

    To play the video, you need to install a newer version of Adobe Flash Player.

    Get Adobe Flash Player

  3. Homogenize the striata in a glass dounce homogenizer (10 strokes of the loose pestle followed by 10 strokes of the tight pestle) with 1 ml of synaptoneurosome buffer kept on ice. The number of strokes might vary depending on the individual homogenizer/pestles and the size of the brain area. All the steps are performed at 4 °C (either on ice or in a 4 °C room). Representative pictures of the homogenates at each step are shown in Figure 1.
  4. Transfer the homogenate into an Eppendorf tube and aliquot 100 μl as an input.
  5. Prepare all the material required for the synaptoneurosome preparation procedure as indicated in Figure 2.
  6. Pre-wet 3 Nylon net filters (100 μm pore) in synaptoneurosome buffer on ice.
  7. Attach a 5 ml syringe without the plunger (syringe #1) to a swinnex filter holder (#1) containing the 3 pre-wetted Nylon net filters (100 μm), as illustrated in Figure 3. Then, attach this swinnex to another 5 ml syringe (syringe #2) without the plunger, which has been attached at the dispensing tip end to a swinnex filter holder containing 1 Mitex membrane filter (10 μm pore) (swinnex filter holder #2). Place on the other side of the swinnex #2 a 1.5 ml Eppendorf tube on ice to collect the sample.
  8. With a 1-ml pipette, load the sample into the end of the barrel of the syringe #1 attached to a swinnex filter holder #1, insert the plunger and push down on the plunger until all the air is gone from the syringe.
  9. Remove the 5 ml syringe #1 and replace it by a 60 ml syringe with the plunger being pulled back. Once attached to the swinnex filter holder #1 containing the 3 Nylon net filters (100 μm), push down on the plunger until all the air is gone from the syringe. This step helps to push down the sample to the barrel of syringe #2.
  10. Remove the swinnex filter holder #1 containing the 3 Nylon net filters (100 μm), place the plunger of the 5 ml syringe #2, which is connected to the swinnex filter holder #2 containing 1 Mitex membrane filter (10 μm), and push down until all the air is gone from the syringe.
  11. Remove the syringe #2 and replace it with a 60 ml syringe with the plunger being pulled back. Once attached to the swinnex filter holder #2, push down on the plunger until all the air is gone from the syringe. At this step, the homogenate should be in the 1.5 ml Eppendorf tube placed on ice.
  12. Centrifuge 1 min at 4,000 x g at 4 °C. Pipette the supernatant into a new Eppendorf tube and discard the pellet. A representative image of how the pellet looks is shown in Figure 1b.
  13. Centrifuge the supernatant for 4 min at 14,000 x g at 4 °C. Discard the supernatant and resuspend the pellet in 100 μl synaptoneurosome buffer. A representative image of how the pellet looks is shown in Figure 1c. (The volume to re-suspend the pellet might change depending on the protein concentration desired. From the striata of one mouse the synaptoneurosome preparation obtained has a protein concentration around 1-2 μg/μl). The pellet can be stored at -80 °C until used.
    Note: In this type of synaptoneurosome preparation we obtained samples containing enrichment of both presynaptic and postsynaptic markers, a substantial reduction of glial markers and absence of nuclear markers (Biever et al., 2015). Moreover, phospho-proteins can be detected as shown in Figure 4.

Representative data


Figure 1. Representative images of the homogenates at different steps. a. Sample obtained after the homogenization of the striata of one mouse as indicated in step 3. b. Sample obtained after the first centrifugation as indicated in step 12. c. Sample obtained after the second centrifugation as indicated in step 13.


Figure 2. Materials required for synaptoneurosome preparation procedure. Place three pre-wetted Nylon net filters (100 μm) in swinnex filter holder #1 and one Mitex membrane filter (10 μm) in swinnex filter holder #2. Mount the apparatus in the following order from the bottom to the top: Eppendorf on ice < swinnex filter holder #2 < 5 ml syringe #2 without plunger < swinnex filter holder #1 < 5 ml syringe #1 without plunger. After loading the sample with a pipette into the barrel of syringe #1, add the plunger and push down until all the air is gone from the syringe. Remove the 5 ml syringe #1 and replace it by a 60 ml syringe with the plunger being pulled back. Once attached to the swinnex filter holder #1, push down on the plunger until all the air is gone from the syringe. This step helps to push down the sample to the barrel of syringe #2. Continue the protocol as indicated from step 10.


Figure 3. Illustration of the mounted apparatus for synaptoneurosome preparation procedure. A 5 ml syringe (syringe #1) is attached to a swinnex filter holder containing 3 Nylon net filters (100 μm) (swinnex filter holder #1) and connected to another 5 ml syringe (syringe #2), which is attached to a second swinnex filter holder containing a Mitex membrane filter (10 μm) (swinnex filter holder #2). A 1.5 ml Eppendorf tube is placed on ice on the other side of the swinnex to collect the sample that was initially loaded into the syringe #1.
Note: Syringes #1 and #2 could be replaced with syringes of different sizes depending on sample volume.


Figure 4. Representative western blots of phospho-proteins in striatal synaptoneurosome preparations. Ten μg per lane of synaptoneurosomal samples were separated in 13% SDS-polyacrylamide gel before electrophoretic transfer onto Immobilon-P membranes. A regular western blot protocol was used including the following antibodies: phospho-S845-GluR1, phospho-T185/Y187-ERK2, phospho-S235/236-rpS6 phospho-S209-eIF4E and β-actin.

Acknowledgments

This work was supported by Inserm, Agence Nationale de la Recherche (Grant ANR-2010-JCJC-1412 to E. V.), and a NARSAD Young Investigator Grant from the Brain and Behavior Research Foundation (to E. P.). A. B. is supported by the Fonds National de la Recherche, Luxembourg (Grant 3977033). E. P. was a recipient of an EMBO Fellowship with the support of European Commission (Grants EMBOCOFUND2010 and GA-2010-267146) and a Marie Curie Intra-European Fellowship IEF327648.

Recipes

  1. Synaptoneurosome buffer (use sterile water of high purity, such as Milli-Q water)
    2.5 mM CaCl2
    124 mM NaCl
    3.2 mM KCl
    1.06 mM KH2PO4
    26 mM NaHCO3
    1.3 mM MgCl2
    10 mM D-(+)-Glucose
    20 mM HEPES (pH 7.4)
    0.15 μM aprotinin
    11 μM leupeptin
    1.5 μM pepstatin
    0.6 mM phenylmethylsulfonyl fluoride
    1 mM sodium orthovanadate*
    100 mM sodium fluoride*
    5 mM sodium pyrophosphate decahydrate*
    40 mM Glycerol phosphate disodium salt hydrate*
    Note: The buffer should be freshly prepared the day of the experiment. Buffer components marked with an asterisk are only required if phospho-proteins are analyzed in the synaptoneurosome preparations.

References

  1. Biever, A., Puighermanal, E., Nishi, A., David, A., Panciatici, C., Longueville, S., Xirodimas, D., Gangarossa, G., Meyuhas, O., Herve, D., Girault, J. A. and Valjent, E. (2015). PKA-dependent phosphorylation of ribosomal protein S6 does not correlate with translation efficiency in striatonigral and striatopallidal medium-sized spiny neurons. J Neurosci 35(10): 4113-4130.
  2. Bramham, C. R. and Wells, D. G. (2007). Dendritic mRNA: transport, translation and function. Nat Rev Neurosci 8(10): 776-789.
  3. Buffington, S. A., Huang, W. and Costa-Mattioli, M. (2014). Translational control in synaptic plasticity and cognitive dysfunction. Annu Rev Neurosci 37: 17-38.


How to cite: Puighermanal, E., Biever, A. and Valjent, E. (2016). Synaptoneurosome Preparation from C57BL/6 Striata. Bio-protocol 6(4): e1735. DOI: 10.21769/BioProtoc.1735; Full Text
